Custom Steel Track Undercarriage Hydraulic Drive for Tunnel Trestle Machinery
25-Ton Heavy Load Reinforced Alloy Steel Crawler Chassis, Four-Drive Hydraulic Motor, 2026 Updated Standard Customization for Tunnel Extreme Working Conditions
This steel track undercarriage is specially designed for tunnel trestle machinery, equipped with four-drive hydraulic motors, supporting full customization on dimensions and structural components. With upgraded material selection and strict production standards based on 2026 MAGEON specification, it is engineered for 25-ton loads in extreme tunnel environments, featuring high durability and operation stability. MAGEON provides custom steel track undercarriages for tunnel equipment with factory-d
Product Name：Hydraulic Drive Custom Steel Track Undercarriage
Target Application：Tunnel trestle machinery, lining trolley, heavy infrastructure machinery
Standard Model：MGS-250B (25-ton grade)
Standard Load Capacity：25 Tons （Support customization）
Drive Mode：Four-drive hydraulic motor
Frame Material：Reinforced high-strength alloy steel
Travel Speed：0-4 Km/h
Gradeability：≤30°
Certification：ISO9001:201
Warranty：1 Year or 1000 Working Hours
MOQ：1 Set
Supply Type：OEM/ODM Customization
Brand：MAGEON
Price: Submit your requirements and contact us for the lowest quote
Core Product Highlights：
Our 25-ton steel track undercarriage is purpose-built for high-intensity tunnel trestle operations. Made of reinforced high-strength alloy steel, it delivers outstanding load-bearing capacity and excellent traction on muddy, rocky or uneven tunnel floors.
⏩Load Capacity: 25 Tons (customizable based on standard series)
⏩Durability: High-wear resistant track shoes and heavy-duty rollers
⏩Precision Performance: Optimized drive system for smooth movement in confined spaces
⏩Application Scenarios: Ideal for tunnel trestles, lining trolleys and heavy infrastructure machinery
Performance & Service Advantages
Controllable Travel Speed: The undercarriage system operates smoothly within the speed range of 0-4 km/h. The controlled speed ensures operation accuracy and safety, helping operators pass through complex terrain easily. The whole system is fully customizable to match individual equipment requirements.
Factory-direct Cost Advantage: Our steel track undercarriage adheres to the concept of providing high-quality products at factory prices. High-performance equipment is accessible with competitive pricing. Made of premium materials with durability-oriented design, it is a reliable, customizable and cost-effective solution for heavy machinery.
2026 MAGEON Standard Steel Track Undercarriage Specification
| Model | A (mm) | B (mm) | C (mm) | D (mm) | Climbing Ability | Travel Speed (km/h) | Rated Load (Kg) |
|---|---|---|---|---|---|---|---|
| MGS-020B | 1545 | 1192 | 230 | 370 | 30° | 2-4 | 1000-2000 |
| MGS-030B | 2000 | 1559 | 300 | 470 | 30° | 2-4 | 3000 |
| MGS-040B | 1998 | 1562 | 300 | 475 | 30° | 2-4 | 4000 |
| MGS-060B | 2465 | 1964 | 350 | 515 | 30° | 1.5 | 5000-6000 |
| MGS-080B | 2795 | 2236 | 400 | 590 | 30° | 1.5 | 7000-8000 |
| MGS-100B | 3000 | 2385 | 400 | 664 | 30° | 1.5 | 10000 |
| MGS-150B | 3203 | 2599 | 450 | 664 | 30° | 1.5 | 12000-15000 |
| MGS-200B | 3480 | 2748 | 500 | 753 | 30° | 1.5-2 | 20000-25000 |
| MGS-300B | 3796 | 3052 | 500 | 838 | 30° | 1.5-2 | 30000-35000 |
| MGS-350B | 4255 | 3500 | 500 | 835 | 30° | 0.8 | 31000-35000 |
| MGS-450B | 4556 | 3753 | 500 | 858 | 30° | 0.8-2 | 40000-45000 |
| MGS-500B | 4890 | 4180 | 500 | 930 | 30° | 0.8-2 | 50000-55000 |
| MGS-600B | 4985 | 4128 | 500 | 888 | 30° | 0.8 | 60000-65000 |
| MGS-700B | 5042 | 4151 | 500 | 1000 | 30° | 0.8 | 70000 |
| MGS-1000B | 5364 | 4358 | 650 | 1116 | 30° | 0.8 | 100000 |
| MGS-1200B | 6621 | 5613 | 700 | 1114 | 30° | 0.8 | 120000 |
Specification Notes：
⏩All above steel track undercarriages are single-sided structure by default; customized connection structures are available with additional cost.
⏩Drive motors can be selected from domestic brands or imported brands, matched according to customer’s actual working conditions.
⏩Optional configurations: slewing bearing, slewing mechanism, central swivel joint, etc.
⏩Rubber pads can be installed on steel tracks to protect the road surface.
Design Optimization Highlights
⏩The design fully balances material stiffness and load capacity. Thicker steel plates are adopted or reinforcing ribs are added at key positions. Reasonable structural design and weight distribution improve vehicle handling stability.
⏩Customized design is available according to upper equipment requirements, including load capacity, dimensions, intermediate connection structure, lifting lugs, crossbeams, rotating platform, etc., to ensure perfect matching between the crawler chassis and upper machinery.
⏩Later maintenance and care are fully considered in design to facilitate disassembly and replacement of parts.
⏩Detailed design guarantees flexible and convenient use, such as motor sealing and dustproof design, various operation instruction labels, etc.
Packaging & Delivery：
⏩Packaging: Steel pallet with wrapping fill, or standard wooden pallet
⏩Port: Shanghai Port or customer-specified port
⏩Transportation: Ocean shipping, air freight, land transportation
Lead Time:
| Quantity (sets) | 1 - 1 | 2 - 3 | >3 |
|---|---|---|---|
| Est. Lead Time (days) | 20 | 30 | To be negotiated |
One-Stop Solution
We provide one-stop procurement service for crawler undercarriage accessories, including rubber tracks, steel tracks, track pads and other supporting parts, which ensures product quality and saves customers' procurement time and comprehensive cost.
Customized steel tracked vehicle products | OEM & ODM Service
Tailored solutions for steel tracked vehicles and distributors worldwide
● Why Choose Our Custom Service
We focus on high-quality steel track undercarriage products for the global engineering machinery market, supporting full-chain customization from design to production.
Stable MOQ, on-time delivery, professional after-sales, helping your brand stand out in the competitive global market.
● Our Customization Scope
We provide flexible customization to meet your brand positioning and market demand.
1. Logo & Marking Customization◆ Laser engraving / Electrochemical etching / Nameplate welding / Forged stamping.
◆ Custom position, size, and style according to your brand standards.
◆ Suitable for steel track undercarriage, track chassis, track shoes, idlers, rollers, etc.
2. Size Customization◆ Custom track width, track length, chassis height, load capacity and installation size.
◆ Suitable for mini excavators, drilling rigs, crawler carriers, and various engineering equipment.
◆ Perfect for machinery manufacturers, OEM factories, brands, and equipment dealers.
3. Material & Performance Customization◆ High-strength alloy steel, wear-resistant steel plate, reinforced track and supporting parts.
◆ High load-bearing, wear-resistant, durable materials that meet EU & US industrial standards.
◆ Support material sample and performance testing before mass production.
4. Packaging Customization◆ Custom fumigation-free wooden box, iron pallet, packaging belt and shipping mark.
◆ Print brand logo, product model, parameter, serial number and handling warnings.
◆ Compliant with international logistics and cross-border transportation requirements.
● Custom MOQ & Production Time
Minimum Order Quantity (MOQ)◆ Logo & marking customization: 1–10 sets.
◆ Size / material customization: 1–10 sets.
◆ Full set customization: 1–5 sets.
◆ (MOQ can be adjusted according to product category, contact us for details).
Production Cycle◆ Sample proofing: 10–15 working days.
◆ Mass production: 20–35 working days after sample confirmed.
◆ Shipping: Sea / Land / Air / Express supported.
● Customization Process
Step One. Inquiry & Demand ConfirmationTell us product type, load capacity, size, quantity and application scenario.
Step Two. Design & QuotationFree design draft + detailed quotation within 24–48 hours.
Step Three. Sample ProductionMake physical sample for your confirmation.
Step Four. Sample ApprovalAdjust until you are completely satisfied.
Step Five. Mass ProductionStrict quality control during production.
Step Six. Inspection & ShipmentFinal inspection, packaging, and on-time delivery.
Step Seven. After-Sales SupportProfessional support for installation, debugging, maintenance and after-sale issues.
