Custom Hydraulic Undercarriage System for Tunnel Vehicle Equipment With Structural Parts
25-Ton Rated Steel Track Complete Undercarriage, Heavy-Duty Hydraulic Drive Crawler Platform for Tunnel Trestle & Engineering Machinery
MAGEON specializes in customized production of hydraulic undercarriage systems for crawler tunnel equipment, providing complete undercarriage assemblies with full structural parts. With nearly 20 years of manufacturing experience, our track system features compact structure, reliable performance, high durability, convenient operation and low energy consumption. All products are manufactured in strict accordance with machining technical standards. This tracked platform is engineered for 25-ton tu
Product Model：MGS-180B
Rated Load Capacity：18,000 kg
Travel Speed：1.5 – 2.0 km/h
Gradeability：0° – 30°
Ground Pressure：≤ 55 kPa
Track Shoe Width：500 mm – 600 mm
Certification：ISO9001:2015 CE
Warranty：1 Year or 1000 Hours
Drive System：Hydraulic Motor + Planetary Reducer
Price: Submit your requirements and contact us for the lowest quote
Core Product Highlights
As a purpose-built hydraulic undercarriage for tunnel vehicle equipment, this complete undercarriage is optimized for high-humidity, muddy and rocky tunnel environments. The reinforced track system delivers strong traction and stable load-bearing performance, and the modular structural design ensures convenient assembly with upper tunnel machinery such as trestles and lining trolleys.
Core Technical Highlights
Heavy-Duty Structural Design
The main frame is welded with Q345B/Q355D high-strength structural steel, providing excellent impact resistance and torsional rigidity for heavy-duty infrastructure construction tasks.
Induction-Hardened Wear System
Key wear parts including track rollers, idlers and track shoes adopt deep induction hardening process (HRC 48-54), which greatly extends service life under abrasive rocky debris working conditions.
Precision Maneuverability
The compact crawler platform is specially optimized for confined tunnel spaces, achieving a smaller turning radius without sacrificing stability and load capacity, and ensuring accurate trestle docking operation.
Modular Customization
As a direct manufacturer, we provide customizable track length, chassis width and hydraulic motor brands (such as Eaton, Rexroth) to match specific machinery requirements of different tunnel projects.
2026 MAGEON Standard Steel Track Undercarriage Specification
| Model 型号 | A – Length (mm) 长度 | B – Width (mm) 宽度 | C – Track Width (mm) 履带宽度 | D – Height (mm) 高度 | Climbing Ability 爬坡能力 | Travel Speed 行走速度 (km/h) | Rated Load 额定承载 (Kg) |
|---|---|---|---|---|---|---|---|
| MGS-020B | 1545 | 1191 | 230 | 370 | 30° | 2-4 | 1000-2000 |
| MGS-035B | 2000 | 1559 | 300 | 470 | 30° | 2-4 | 3000-4000 |
| MGS-060B | 2500 | 1964 | 350 | 520 | 30° | 2-4 | 5000-7000 |
| MGS-080B | 2795 | 2236 | 400 | 590 | 30° | 2-4 | 8000-9000 |
| MGS-100B | 3000 | 2441 | 400 | 610 | 30° | 2-4 | 10000-13000 |
| MGS-150B | 3000 | 2385 | 450 | 662 | 30° | 2 | 15000-18000 |
| MGS-180B (Tunnel Special) | 3300 | 2600 | 500 | 720 | 30° | 1.5-2 | 18000 |
| MGS-200B | 3510 | 2517 | 500 | 730 | 30° | 2 | 20000-25000 |
| MGS-250B (Tunnel Special) | 4100 | 2800 | 500 | 750 | 30° | 2-4 | 25000 |
| MGS-300B | 3832 | 3125 | 500 | 835 | 30° | 2 | 30000-35000 |
| MGS-450B | 4556 | 3753 | 500 | 858 | 30° | 2 | 40000-45000 |
| MGS-600B | 4600 | 3743 | 500 | 920 | 30° | 2 | 50000-60000 |
| MGS-800B | 5042 | 4346 | 500 | 1000 | 30° | 2 | 70000-80000 |
Specification Notes：
The above complete undercarriage is single-sided structure by default; customized middle frame and structural parts are available with additional cost.
Hydraulic motors can be selected from domestic or imported brands, matched according to actual working conditions of the tracked platform.
Optional configurations: slewing bearing, dozer blade, central swivel joint, etc.
Both steel track and rubber track undercarriage solutions are available for tunnel applications.
Packaging & Delivery
Packaging: Steel pallet with wrapping protection, or standard wooden pallet for complete undercarriage assembly
Port: Shanghai Port or customer-specified port
Transportation: Ocean shipping, air freight, land transportation
Lead Time:
| Quantity (sets) | 1 - 1 | 2 - 3 | >3 |
|---|---|---|---|
| Est. Lead Time (days) | 20 | 30 | To be negotiated |
One-Stop Solution
We provide full-category one-stop procurement service for crawler platform accessories, including track roller, top roller, idler, sprocket, tension device, rubber track, steel track and other supporting parts. With competitive factory prices, it helps customers save procurement time and comprehensive costs.
Customized steel tracked vehicle products | OEM & ODM Service
Tailored solutions for steel tracked vehicles and distributors worldwide
● Why Choose Our Custom Service
We focus on high-quality steel track undercarriage products for the global engineering machinery market, supporting full-chain customization from design to production.
Stable MOQ, on-time delivery, professional after-sales, helping your brand stand out in the competitive global market.
● Our Customization Scope
We provide flexible customization to meet your brand positioning and market demand.
1. Logo & Marking Customization◆ Laser engraving / Electrochemical etching / Nameplate welding / Forged stamping.
◆ Custom position, size, and style according to your brand standards.
◆ Suitable for steel track undercarriage, track chassis, track shoes, idlers, rollers, etc.
2. Size Customization◆ Custom track width, track length, chassis height, load capacity and installation size.
◆ Suitable for mini excavators, drilling rigs, crawler carriers, and various engineering equipment.
◆ Perfect for machinery manufacturers, OEM factories, brands, and equipment dealers.
3. Material & Performance Customization◆ High-strength alloy steel, wear-resistant steel plate, reinforced track and supporting parts.
◆ High load-bearing, wear-resistant, durable materials that meet EU & US industrial standards.
◆ Support material sample and performance testing before mass production.
4. Packaging Customization◆ Custom fumigation-free wooden box, iron pallet, packaging belt and shipping mark.
◆ Print brand logo, product model, parameter, serial number and handling warnings.
◆ Compliant with international logistics and cross-border transportation requirements.
● Custom MOQ & Production Time
Minimum Order Quantity (MOQ)◆ Logo & marking customization: 1–10 sets.
◆ Size / material customization: 1–10 sets.
◆ Full set customization: 1–5 sets.
◆ (MOQ can be adjusted according to product category, contact us for details).
Production Cycle◆ Sample proofing: 10–15 working days.
◆ Mass production: 20–35 working days after sample confirmed.
◆ Shipping: Sea / Land / Air / Express supported.
● Customization Process
Step One. Inquiry & Demand ConfirmationTell us product type, load capacity, size, quantity and application scenario.
Step Two. Design & QuotationFree design draft + detailed quotation within 24–48 hours.
Step Three. Sample ProductionMake physical sample for your confirmation.
Step Four. Sample ApprovalAdjust until you are completely satisfied.
Step Five. Mass ProductionStrict quality control during production.
Step Six. Inspection & ShipmentFinal inspection, packaging, and on-time delivery.
Step Seven. After-Sales SupportProfessional support for installation, debugging, maintenance and after-sale issues.
● Custom Case Show (Real Photos)
Please leave your customization requirements, and we will contact you as soon as possible!
Leave your requirements, we'll get back to you within 24 hours.
